Pine is a professional solar product supplier, lithium ion battery manufacturer and solar energy system factory in China.
The adoption of the latest technology improves the quality of product.And the widespread use in Energy Storage Container of Customized Power Wall Battery Llithium Battery Lifepo4 Battery 48v 50ah Power Wall Energy System helps it win a lot of attention in the market.Besides It is designed to meet the different demand preferences.
Produced with the latest technology, Customized Power Wall Battery Llithium Battery Lifepo4 Battery 48v 50ah Power Wall Energy System ranks top in the industry. Pine Energy (Shenzhen)co., Ltd can make your Customized Power Wall Battery Llithium Battery Lifepo4 Battery 48v 50ah Power Wall Energy System famous and visible in the eyes of your target buyers and get a great response from them. Pine Energy (Shenzhen)co., Ltd has always insisted on winning by "quality", and has won wide recognition and praise from many companies with high-quality services.
| Place of Origin | Guangdong, China | Brand Name | Pine |
| Model Number | PN2000 | Battery Type | storage battery pack |
| Product name | Lithium Battery | Chemistry | LifePo4 |
| Configuration | 16S4P | Case Material | ABS |
| Enclosure Protection | IP20 | Short Circuit Protection | 200-400μs |
| Low Temperature Cut-off Charge | 32℉[0℃][Customized] | High Temperature Cut-off Charge | 129.2℉[54℃][Customized] |
| Shipping Classification | UN3480,CLASS9 |
Discharge Specifications | Charge Specifications | ||||
Maximum Continuous Discharge Current | 100A | Recommend Charge Current | 5A-40A | ||
Peak Discharge Current | ≤150A | Maximum Charge Current | 50A | ||
BMS Discharge Current Cut-off | 130A±20A [90±10ms] | Recommed Charge Voltage | 52.5-54V | ||
Recommend Low Voltage Disconnect | 42V | BMS Charge Voltage Cut-off | 54V[3.75±0.1V] | ||
BMS Discharge Voltage Cut-off | 42V[2.8±0.08 vpc] [100±50ms] | Reconnect Voltage | 51.8V[3.45±0.1V] | ||
Reconnect Voltage | 10V[2.5±0.1vpc] | Balancing Voltage | 52.5V[3.5±0.025vpc] | ||
Short Circuit Protection | 200-400μs | Balancing Current | 35±5mA | ||
Temperature Specifications | ||
Discharge Temperature | -4 to 140℉[-20 to 60℃] | |
Charge Temperature | 32 to 113℉[0 to 45℃] | |
Storage Temperature | 23 to 113℉[-5 to 45℃] | |
BMS High Temperature cut-off Discharge | 149℉[65℃][Customized] | |
Reconnect Temperature | 122℉[50℃][Customized] | |
Low Temperature Cut-off Charge | 32℉[0℃][Customized] | |
High Temperature Cut-off Charge | 129.2℉[54℃][Customized] | |
